Description
RAISED ACCESS FLOORING
FINISH OPTIONS
| Factory Laminated Conductive Homogeneous PVC Finish | |||
| Physical Properties | Chemical Properties (Anti-Corrosion) | ||
| Item | Index | Item | Index |
| Length x Width | 600 x 600mm, 610 x 610mm | HCL | Pass |
| Thickness | 2.0mm, 2.5mm, 3.0mm | Alcohol | Pass |
| System Resistance | 104 – 106Ω | Acetone | Pass |
| Decay Time | 1000V to 100V (Less than 2 secs) | NaOH Aqueous | Pass |
| Rate of Size Change at Heating | Less than 0.20% | Gasoline | Pass |
| Starting Voltage | Less than 100V | Normal Detergent | Pass |
| Wearing | Less than 0.02g/cm2 | ||
| Combustion Property | Less than 10 secs (FV-0) | ||
RAISED ACCESS FLOORING
SYSTEM PERFORMANCE CRITERIA
System performance criteria are the most important to consider because they represent the performance in a typical installation.Raised access floor only criteria such as concentrated load is often used to specify floor systems however, the test is not representative of an actual installation because it is performed with the raised access floor testing blocks, not actual understructure.
| System Performance Criteria | ||||||
| System Type | Static Loads | Rolling Loads | ||||
| Panel | Panel Size | Concentrated Load |
Safety Factor (min.2.0) |
Ultimated load | 10 Passes | 10,000 Passes |
| FS800 | 600x600x35mm 610x610x35mm |
368kg/800lbs | Pass | 736kg/1600lbs | 318kg 700lbs |
275kg 600lbs |
| FS1000 | 600x600x35mm 610x610x35mm |
454kg/1000lbs | Pass | 909kg/2000lbs | 368kg 800lbs |
318kg 700lbs |
| FS1250 | 600x600x35mm 610x610x35mm |
568kg/1250lbs | Pass | 1136kg/2500lbs | 454kg 1000lbs |
368kg 800lbs |
| FS1500 | 600x600x35mm 610x610x35mm |
681kg/1500lbs | Pass | 1363kg/3000lbs | 568kg 1250lbs |
454kg 1000lbs |
| FS2000 | 600x600x35mm 610x610x35mm |
909kg/2000lbs | Pass | 1818kg/4000lbs | 681kg 1500lbs |
568kg 1250lbs |
| FS2500 | 600x600x35mm 610x610x35mm |
1136kg/2500lbs | Pass | 2272kg/5000lbs | 909kg 2000lbs |
681kg 1500lbs |
| FS3000 | 600x600x35mm 610x610x35mm |
1363kg/3000lbs | Pass | 2726kg/6000lbs | 1136kg 2500lbs |
909kg 2000lbs |
*A tests are performed using CISCA’s Recommend Test Procedures for Access Floors with the exception of Design Load
1. Raised access floor design load is tested using CISCA Concentrated Load test method on actual understructure instead of steel blocks. Design load is determined by taking the lesser value of ultimate load divided by two or the point at which permanent damage begins to occur (yield point).
2. Raised access floor safety factor is the multiple of Design load to the Ultimate Load. International standards and Dawn Modular Floor recommend’ a minium of 2.
2. Raised access floor safety factor is the multiple of Design load to the Ultimate Load. International standards and Dawn Modular Floor recommend’ a minium of 2.
RAISED ACCESS FLOORING
UNDERSTRUCTURE OPTIONS
-
Standard FH Pedestal
(OD22.3×1.5mm tube) -
Heavy Duty FH Pedestal
(OD32x1.5mm tube) -
Extra Heavy Duty FH Pedestal
(OD45x1.5mm tube) -
Seismic FH Pedestal
(OD60x1.5mm tube) -
Standard Stringer
(1.0mm / 1.8mm thickness)
RAISED ACCESS FLOORING
INSTALLATION
The finished raised access floor wil be rigid, free from vibration and rocking panels within a 3mm level over the entire space. Panels will be accurately cut to fit around all permanent features. All whole panels will be completely interchangeable allowing for any future changes. The raised access foor will maintain these origina conditions when sufficient panels have been removed for normal underfloor access.
RAISED ACCESS FLOORING
BENEFITS
● Electrostatic Discharge Protection: Conductive steel PVC raised access flooring helps to prevent the buildup of static electricity and safely dissipate any electrical charges. This provides superior protection against electrostatic discharge (ESD), making it ideal for areas with sensitive electronic equipment.
● Chemical Resistance: The PVC covering of conductive steel PVC raised access flooring provides excellent chemical resistance, making it resistant to many common chemicals found in data centers.
● Improved Aesthetics: Conductive steel PVC raised access flooring is available in a range of finishes and colors, allowing for customizable design options that can enhance the overall aesthetics of the data center.
● Easy Maintenance: The PVC covering of conductive steel PVC raised access flooring is easy to clean and maintain, providing long-lasting performance with minimal effort.
● Enhanced Durability: The combination of steel and PVC materials in conductive steel PVC raised access flooring provides excellent durability and long-term performance, even in high-traffic areas.
● Enhanced Safety: Conductive steel PVC raised access flooring is often made from fire-resistant materials, providing an additional layer of safety and protection for the data center.
● Chemical Resistance: The PVC covering of conductive steel PVC raised access flooring provides excellent chemical resistance, making it resistant to many common chemicals found in data centers.
● Improved Aesthetics: Conductive steel PVC raised access flooring is available in a range of finishes and colors, allowing for customizable design options that can enhance the overall aesthetics of the data center.
● Easy Maintenance: The PVC covering of conductive steel PVC raised access flooring is easy to clean and maintain, providing long-lasting performance with minimal effort.
● Enhanced Durability: The combination of steel and PVC materials in conductive steel PVC raised access flooring provides excellent durability and long-term performance, even in high-traffic areas.
● Enhanced Safety: Conductive steel PVC raised access flooring is often made from fire-resistant materials, providing an additional layer of safety and protection for the data center.
● Excellent Load Capacity: The steel panels of conductive steel PVC raised access flooring have a high load capacity, making it suitable for heavy equipment and machinery found in data centers.
