Description
CONSTRUCTION OPTIONS
| Panel Size Options | 600x600x30mm, 600x600x40mm |
| Covering Options | HPL Finish, PVC Finish |
| GI Steel Sheet Options | 0.3mm , 0.4mm , 0.5mm,1.0mm,Aluminum foil |
| Installation Options | Gravity Lay with Stringer System |
Panel Edge Construction Side View
SYSTEM PERFORMANCE CRITERIA
System performance criteria are the most important to consider because they represent the performance in a typical installation. Panel only criteria such as concentrated load is often used to specify floor systems however, the test is not representative of an actual installation because it is performed with the panel testing blocks, not actual understructure.
| System Performance Criteria | ||||||
| System Type | Static Loads | Rolling Loads | ||||
| Panel | Panel Size | Concentrated Load |
Safety Factor (min.2.0) |
Ultimated load | 10 Passes | 10,000 Passes |
| PEW1000 | 600x600x30mm | 454kg/1000lbs | Pass | 909kg/2000lbs | 368kg 800lbs |
318kg 700lbs |
| PEW1250 | 600x600x40mm | 568kg/1250lbs | Pass | 1136kg/2500lbs | 454kg 1000lbs |
368kg 800lbs |
*A tests are performed using CISCA’s Recommend Test Procedures for Access Floors with the exception of Design Load
1. Design load is tested using CISCA Concentrated Load test method on actual understructure instead of steel blocks. Design load is determined by taking the lesser value of ultimate load divided by two or the point at which permanent damage begins to occur (yield point).
2. Safety factor is the multiple of Design load to the Ultimate Load. International standards and Dawn Modular Floor recommend’ a minium of 2.
2. Safety factor is the multiple of Design load to the Ultimate Load. International standards and Dawn Modular Floor recommend’ a minium of 2.
UNDERSTRUCTURE OPTIONS
-
Standard CS Pedestal
(OD22.3×1.5mm tube)
-
Heavy Duty CS Pedestal
(OD38x1.5mm tube) -
Extra Heavy Duty CS Pedestal
(OD45x1.5mm tube) -
Standard CS Stringer
(1.0mm / 1.5mm)
INSTALLATION
The finished access floor wil be rigid, free from vibration and rocking panels within a 3mm level over the entire space. Panels will be accurately cut to fit around all permanent features. All whole panels will be completely interchangeable allowing for any future changes. The access foor will maintain these origina conditions when sufficient panels have been removed for normal underfloor access.
ADVANTAGES
● Electrostatic Discharge (ESD) Control: The primary benefit of Anti Static Woodcore Raised Access Flooring is its ability to control electrostatic discharge. It safely dissipates static electricity, protecting sensitive electronic equipment from potential damage.
● Strength and Stability: Made with a high-density woodcore, this flooring type offers excellent load-bearing capacity, allowing it to support heavy equipment and high foot traffic.
● Ease of Maintenance: The raised design of the flooring creates an accessible underfloor space for utilities such as cabling and HVAC systems. This design allows for easy maintenance and upgrades without disrupting the workspace.
● Durability: These floors are built to last. The woodcore is usually encapsulated in steel or another metal, offering a high degree of resistance to wear and tear.
● Aesthetics and Versatility: Anti Static Woodcore Raised Access Flooring can be finished with a variety of high-pressure laminates or vinyl coverings, providing a professional and clean aesthetic that fits with various room designs.
● Sound Damping: The composition of the flooring can contribute to a quieter environment by reducing sound transmission.
● Fire Resistance: Many Anti Static Woodcore Raised Access Floors are treated to be fire-resistant, providing an added layer of safety.
● Strength and Stability: Made with a high-density woodcore, this flooring type offers excellent load-bearing capacity, allowing it to support heavy equipment and high foot traffic.
● Ease of Maintenance: The raised design of the flooring creates an accessible underfloor space for utilities such as cabling and HVAC systems. This design allows for easy maintenance and upgrades without disrupting the workspace.
● Durability: These floors are built to last. The woodcore is usually encapsulated in steel or another metal, offering a high degree of resistance to wear and tear.
● Aesthetics and Versatility: Anti Static Woodcore Raised Access Flooring can be finished with a variety of high-pressure laminates or vinyl coverings, providing a professional and clean aesthetic that fits with various room designs.
● Sound Damping: The composition of the flooring can contribute to a quieter environment by reducing sound transmission.
● Fire Resistance: Many Anti Static Woodcore Raised Access Floors are treated to be fire-resistant, providing an added layer of safety.
